| Product Glance | Value | |||
| Version Crypto Algorithm/Coins |
DR5 Blake256R14 |
|||
| Hashrate, TH/s | Normal 35.00 |
Lower Power 25.00~26.00 |
||
| Reference power on wall, Watt | 1610 | 1000~1040 | ||
| Reference power efficiency on wall @25℃, J/TH | 46.00 | 40.00 | ||
| Detailed Characteristics | Value | |||
| Min | Typ | Max | ||
| Hashrate & Power | ||||
| Hashrate, TH/s | Normal Lower Power |
35.00 25~26.00 |
35.95 +3%(1-1) |
|
| Power efficiency on wall @25℃, J/TH | Normal Lower Power |
46.00 40.00 |
49.22 42.80 |
|
| Power efficiency on wall @40℃, J/TH | Normal Lower Power |
47.53 41.42 |
50.86 44.32 |
|
| Power on wall, Watt (1-1) | Normal Lower Power |
1610 1000 |
1828 1187 |
|
| Power supply AC input voltage, Volt (1-2) | 200 | 220 | 240 | |
| Power supply AC input current, Volt (1-3) | Normal Lower Power |
7.32 4.55 |
9.14 5.94 |
|
| Power supply Input AC Frequency Range, Hz | Normal Lower Power |
47 | 50 | 63 |
| Hardware Configuration | ||||
| Networking connection mode | RJ45 Ethernet 10/100M | |||
| Miner Size (Length*Width*Hight, w/o package), mm (2-1) | 238*178*297 | |||
| Net weight, kg (2-2) | 7.75 | |||
| Noise, dBA @25℃ (2-3) | 76 | |||
| Environment Requirements | ||||
| Operation temperature, ℃ | 0 | 25 | 40 | |
| Storage temperature, ℃ | -40 | 25 | 85 | |
| Operation humidity, RH | 5% | 95% | ||
Notes:
(1-1) In Low Power Mode, Max Hashrate should be Typ hashrate *103%
(1-2) Min condition: 25°C, min J/TH, typical hashrate Max condition: 40°C, max J/TH, max hashrate
(1-3) Caution: Wrong input voltage may probably cause miner damaged
(1-4) Typ condition: min reference power, typical AC input voltage Max condition: max reference power, min AC input voltage
(2-1) Including PSU size
(2-2) Including PSU weight
(2-3) Max condition: Fan is under max RPM(rotation per minute).
